LKB FS

LKB-FS series offers a compact, tank mounted compressor complete with refrigerated air dryer and filtration as one stand-alone unit. Perfect for installations tight on available space.
Model LKB5-15 FS

Full feature package design

• Compact full feature design
• Compressor and dryer installed on 500 litre vertical air receiver
• Built in filtration and condensate removal
• Fits through standard doorway
• Front access for serviceability so can be installed in tight spaces

LKB-FS is a full feature air station design which incorporates a rotary screw air compressor, refrigerated air dryer, line filtration and condensate drain all in one compact package. All components are mounted on a 500 litre vertical air receiver designed to fit through a standard doorway. This full feature option provides the customer with all services in a small footprint which can easily be transported to any factory location for point of use compressed air.

Technical specifications

Motor power: 5.5kW - 22kW
Air discharge: 0.5 m?/min-3.8 m?/min
Working pressure: 8 / 10 bar
